设计标准

ASME B16.34

API 6D

PED 97/23/EC

Fire-safe: API 607, ISO 10497

FE (Fugitive Emission): ISO 15848, TA LUFT VDI/VDE 2440

ISO 9001

Anti-static: DIN EN ISO 17292

设计范围

Size Range:

DN 15 to 50mm (DIN)

NPS 1/2" to 2" (ASME)

Pressure Class Range:

PN 16 to PN 100 (DIN)

Class 150 to 600 (ASME)

Temperatures:

-48°C to 230°C

-54°F to 446°F

Seating Material: Soft seated

特点&优势

Environmental compliance via end-entry design that reduces fugitive emissions

Reliable performance to highest zero-tightness demands from FCI 70-2 Class VI seat design

Improved plant and personnel safety with ISO 15848 compliance

配置
